Fireplace cassette KRATKI KDZ 6 kW
Fireplace cassette KRATKI KDZ 6 kW
Regular price
€1.090 EUR
Regular price
Sale price
€1.090 EUR
Unit price
/
per
Tax included.
Overview
Modern KDZ fireplace cassette insert is compact heating equipment.
It can be fitted into existing open fireplaces.
Thanks to the applied solutions, such as turbines (forced convection), the cassette insert enables very effective use of heat from combustion of wood, making the equipment a very economical source of heat.
At a glance
- Brand: Kratki
- Heat output: 6 kW
- Fuel: Seasoned deciduous wood (humidity ≤20%)
- Efficiency: 78%
- Width: 73 cm
- Height: 52 cm
Technical details
Product information
| Brand | Kratki |
|---|---|
| Reference | KASETA/KDZ |
| Availability | Out of stock |
Performance
| Nominal power (kW) | 6 |
|---|---|
| Heating power range (kW) | 3.0 - 8.0 |
| Thermal Efficiency (%) | 78 |
| Seasonal Energy Efficiency (%) | 68 |
| Heat output for space heating (kW) | 6 |
| Fuel type | Seasoned deciduous wood (humidity ≤20%) |
Dimensions
| Max billet length (cm) | 30 |
|---|---|
| Width (cm) | 73 |
| Height (cm) | 52 |
| Depth (cm) | 42.6 |
| Weight (kg) | 110 |
Installation
| Flue gas temperature (oC) | 260 |
|---|---|
| diameter of the flue gas outlet | 150 |
| Flue gas mass flow (g/s) | 6.6 |
Compliance
| Energy class | A |
|---|---|
| Certificates | Ecodesign, BImSchV 2 |
Technical details
| CLOSING | No |
|---|---|
| Base material | Steel |
| Door opening | Left |
| EEI | 103.1 |
| CO emission (at 13% O2) ≤ given in % | 0.099 |
| CO emission (mg/m3) | 1234 |
| Pollen emission (mg/m3) | 23 |
| NOx emission (mg/m3) | 49 |
| OGC emission (mg/m3) | 74 |
| Equipment | Ashpan, Combustion chamber lining, Decorative glass |
| EAN | 5901350016527 |
