Overview
Width 809mm Height 481mm Depth 382mm Weight 129kg Flame visibility area (W x H) 590mm x 259mm Nominal Heat Output & Range 5.0kW (1.7-7kW) Maximum log length 300mm (12”) Energy Efficiency Class A High efficiency 79.6% Top flue connection Internal Ø - 153mm (6”)
At a glance
-
Heat output: 5.0kW (1.7-7kW)
-
Efficiency: A
-
Width: 809mm
-
Height: 481mm
-
Depth: 382mm
-
Flue size: Internal Ø - 153mm (6”)
Technical details
Product information
| Reference |
9920 |
| Availability |
In stock |
Performance
| Nominal Heat Output & Range |
5.0kW (1.7-7kW) |
| Energy Efficiency Class |
A |
| High efficiency |
79.6% |
Dimensions
| Width |
809mm |
| Height |
481mm |
| Depth |
382mm |
| Weight |
129kg |
| Maximum log length |
300mm (12”) |
Installation
| Top flue connection |
Internal Ø - 153mm (6”) |
Technical details
| Flame visibility area (W x H) |
590mm x 259mm |
Downloads
