Water heating fireplace KRATKI ZUZIA DECO 12 kW Ø 200

Water heating fireplace KRATKI ZUZIA DECO 12 kW Ø 200

€1.607 EUR
€1.607 EUR
Sale Sold out
Tax included.

Overview

MAXIMUM USE OF ENERGY The body and the front of the insert are resistant to high temperatures thanks to the high quality steel used in production.

Built in smoke tubes and high flue, which increase the heat exchange surface.

Increased heat exchange surface due to built-in smoke tubes and high flue.

At a glance

  • Brand: Kratki
  • Heat output: 12 kW
  • Fuel: Seasoned deciduous wood (humidity ≤20%)
  • Efficiency: 81%
  • Width: 65.2 cm
  • Height: 86.9 cm
Technical details

Product information

Brand Kratki
Reference ZUZIA/PW/15/W/DECO
Availability Out of stock

Performance

Nominal power (kW) 12
Heating power range (kW) 5.0 - 15.0
Thermal Efficiency (%) 81
Water capacity (l) 38
Average power from water (kW) 8
Heat output for space heating (kW) 4
Seasonal Energy Efficiency (%) 71
Fuel type Seasoned deciduous wood (humidity ≤20%)

Dimensions

Max billet length (cm) 40
Width (cm) 65.2
Height (cm) 86.9
Depth (cm) 48.9
Weight (kg) 182

Installation

Flue gas temperature (oC) 254
Minimum required active field of outlet grilles (cm2) 240
diameter of the flue gas outlet 200

Compliance

Energy class A
Certificates Ecodesign, BImSchV 2

Technical details

Max working pressure (bar) 2
Minimum required active area of inlet grilles (cm2) 120
Door opening Left
Base material Steel, Cast iron
CLOSING No
CO emission (mg/m3) 1087
NOx emission (mg/m3) 108
OGC emission (mg/m3) 68
EEI 106
Pollen emission (mg/m3) 33
CO emission (at 13% O2) ≤ given in % 0.086
EAN 5901350062753
Equipment Ashpan, Combustion chamber lining, Decorative glass
